Tim Evans’ superlight cuben fibre folding kayaks

Tim-Evans-Cuben-Kayak02Tim Evans from Vancouver got in touch via the busy IK&P press office to tell us about his new 10lb (4.5kg) IK. Made from a super strong, light but expensive wonder fabric called Cuben Fibre which regularly features in discussions at Backpacking Light, the 14-foot IK was made to fill the gap between packrafts like his Yak and super light Supai, and a regular, faster IK.
Having worked on his own gear, Tim’s design is based on one of Tom Yost’s well-known MYO packboat templates which I’ve come across in my online travels. He writes:
Tim-Evans-Cuben-Kayak04Commercial inflatable kayaks are much faster [than packrafts], but are too heavy. I don’t want to carry more then 30lbs, which has to include the boat, paddling gear, camping gear and food. What I really wanted was a fast IK that weighed 10 pounds or less. It didn’t exist (as far as I could tell), so I made one. Here’s a video showing the boat.

Tim-Evans-Cuben-Kayak08It’s 14 feet long and weighs 10lbs. As you can see in the video, it’s a lot faster than a packraft. The key to the light weight was Tom Yost’s very simple design concept, modified a bit, and married with the lightest available materials. The hull skin material is very strong, but abrasion resistance is it’s weakness. This can be a problem with barnacle encrusted rocks (as I have found) when paddling in the ocean, but in the lakes I made the boat for, there should be few if any sources of abrasion. The skin of the boat weights about 1.6 lbs, interestingly about the same weight as the Supai.
homemade-pfdI made the kayak to redo a trip I did last summer in the Supai. I made an inflatable PFD for that trip (left), which I have tested in the water and it supports me quite well. Since I take several inflatable cushions with me anyway, the extra weight for the PFD is just 260 grams for the shell.

[Regarding the poor abrasion resistance] I think it comes down to calculated risk. I always have some kind of backup plan if the worst case happens. While the kayak skin is a bit delicate, I will take various repair tapes and Aquaseal with me. And since I made the boat myself, I should be able to repair it in the field if I have to.
Tim-Evans-Cuben-Kayak09As for stability, the boat is no worse than any other narrowish kayak. But I have one final ace up my sleeve. I will be taking my Supai as a back up boat (right)! At 1.5 lbs, why not. Since I have already done the trip in the Supai, in case the kayak became so damaged as to be unrepairable (which is quite unlikely), Tim-Evans-Supai01I just do the rest of the trip as I did last time. I will stay within a swim of the shoreline of the lakes and the water is not that cold, so a dunking should not be life-threatening. Sure, there are always unforeseeable hazards, but I think life is too short to play it too safe.

Tim’s summer 2014 pics with the kayak on the Powell Forest Canoe Trail
Tim’s 17-foot version built in 2015


Supai Flatwater Canyon II packraft review

Full trip report here (mostly walking)
June 2015: Supai Matkat review

supai196At a verified 670g (23.6oz) including an added grab line, Supai Adventure Gear’s Flatwater Canyon II ($300/€290) must be among the world’s lightest and most compact boats. Before a winter storm blew our plan off supai01the map, the trip we’d lined up in northwest Scotland was ideal for the Flatwater: short crossings saving lengthy detours or risky deep wading, but no extendedor exposed paddling.

Examining the deflated raft beforehand, it became clear it was ingeniously composed of just four pieces of flat material: the top and bottom ‘rings’ which define the hull shape, an inner hull wall joining the top to bottom, and the floor fixed under the completed ring. You could almost make one yourself were it not for the heat-welded seams of at least half an inch (one inch on the floor).
su-msrfabdromoNo fabric details on SAG’s website, but the Packraft Store states: ’75 denier polyester with single, innerside urethane coating’. This whole denier thing can be a bit misleading, the raft fabric looks and feels similar in thickness to my MSR Dromlite water bags (right) made from 200 denier, PU-coated Cordura (nylon?), but the Flatwater polyester has what looks like a reassuring ripstop texture (visible left). And as we know from our studies in IK hull fabrics, polyester stretches less than nylon and so is more suited to inflatable boat applications than compact water storage.
su-tabsu-floorspotsWhere the seams overlap on the outside edge they’ve included seven reinforced tabs (right) to use as attachment points (a weak point on my non-ripstop Dromlites, even with an eyelet). The floor is made of the same weight fabric and shows what look like ‘spot welds’ along the inch-wide seam (left).
supai03That’s it, apart from a big threaded inflation port onto which screws a white cap fitted with a 18-inch hose topped with a blue twist-lock valve (left). You blow the boat up by mouth (took me about 45 breaths) then top up to operating pressure with the twist lock, like on an Alpacka. But unlike an Alpacka the long hose means you’re able to further top up the pressure from the water where inflatable boats initially sag as they cool. Plus you could potentially manage a slow leak in the same way.Sevylor TrailBot
The hull form tapers and narrows towards the bow to resemble a blunt wedge, similar to old Sevylor Trail Boat (right). Like all packrafts and even slackrafts, the added buoyancy (tube diameter) in the stern counteracts the mass of the paddler’s weight. There’s no seat and a new boat comes with a repair kit with full repair instructions on the SAG website.

The dimensions I’ve come up with are:
• 157cm long
• 92cm wide
• 106cm long inside
• 41cm max inner width
• 17cm wide at the feet
• 28cm high at the back (= tube diameter)
• 22cm high at the front (≤ tube diameter)


candimsSome of my measurements (checked several times and now confirmed by the Packrafting Store) vary greatly from those still posted on the SAG website in mid-2015 (snapshot above right) which have their Canyon over 10% bigger, inside and out. Even if they’re factoring in ‘paddler squidge’ making more room inside by pushing on the hull, that won’t make the boat seven inches longer. If this large discrepancy matters to you I’d suggest you contact the vendor before buying.
As for buoyancy, SAG quote ‘250lb’ (113.4kg) while the Packraft Store suggests a more realistic 95kg. Robin briefly paddled the raft with his pack which we thought added up to about 95-100kg. That felt like the limit once a light breeze came up the valley, and required gentle paddling to avoid too much cyclic bobbing and possible swamping.
supai99With the weight; the Store states 633g, SAG quote 24oz (680g). As mentioned, with a grab line and traces of dirt, our boat comes in at 670g on the IK&P calibrated kitchen scales (left). I won’t quibble over 40 grams; to be able to paddle across a loch in a boat weighing less than my trousers is quite something.

On the water
supai04su-mapThe air was calm but temperatures were close to freezing as we set off to cross the eastern narrows on Loch Lurgainn below Stac Pollaidh mountain.
We’d originally planned to come over in the other direction from the Culnacraig shore, but the storm which went on to wreak havoc across Britain nixed that plan (story here). So today we were just taking a 10-mile day trip with a short paddle, from Stac car park southwest back to Altandu.


I tried to get directly over the two boats to get an equal perspective but I still think this shot makes the Supai appear a little smaller than it really is. I make the Yak ~42% longer.

‘Fragile and small’ had been Robin’s first impressions after Sven from the Packraft Store in Germany sent us the raft to evaluate. Robin had recently upgraded to a couple of Gumotex Twist IKs so may not have been impressed by the Supai’s thin fabric. I had more faith in that, but as for the size, I too anticipated that SAG had cut it a bit fine with the Flatwater II, even if it lived up to their motto: ‘where every ounce counts’.
Supai-and-Exped-Schozzel-PumpbagDown on the loch shore, even with a helpful breeze to fill my Yak’s bag, inflation time for both boats was actually the same, although by the end of it Robin was staggering around a bit. As Tim Evans found on his trip, other inflator bags (right) can be adapted to avoid passing out.
Now, laid alongside my Alpacka Yak (same width but 66cm or over two feet longer), to me the Flatwater’s proportions rather too closely resembled a slackraft I skinned from a Sevylor pool toy a year or two back. I knew that with my weight of about 100kg in gear, I’d be pushing this boat’s limit. Without a drysuit I didn’t want to risk it.
supai10It took some prodding to get packrafting newb Robin (80kg + clothes) in the Supai and I’m not sure I blame him. A sudden move could see the stern dip down and douse the butt. supai08After fitting his closed cell mat to keep warm and protect the thin floor, he set off for a quick spin and soon realised there wasn’t so much to worry about. Paddling gingerly with his home-made paddle (a broom stick, two sawn-down buckets and zip ties) he did a few loops while learning to control the annoying yawing you get with short packrafts and slackrafts, as well as managing the less welcome bobbing which might amplify into a back-end pour over. Yawing keeps the speed down which may be just as well. Start paddling too fast and the bow will rise with a corresponding drop at the stern when slowing down, again risking a pour over in wavy conditions.
supai14Having established he wasn’t going to sink with all hands, I lowered Robin’s 10-kg pack onto his legs then hopped into my Yak. The pack’s added frontal weight should minimise the Supai’s yawing – at least that’s the effect on my Yak. But it’s well known that first time in a new packraft, especially a short one like the Flatwater, paddling efficiently is an acquired knack. Our extra chilly scenario (not helped by his experimental B&Q paddle) meant that Robin couldn’t really relax or bomb around in the Supai. (I tried hisBQ B&Q but soon sent it back as it brought in unwanted splash all over my boat). A gust rolled up the valley, rippling the loch’s surface, adding further to the feeling of anxiety in the Supai. From my PoV it looked like the stern was more than half sunk at times – and half sunk on a round tube makes pour-overs all the easier.
supai18I skimmed over to the other side and got out to get some long shots and was reminded yet again what a great boat my Yak is. No worries about getting in clumsily, sudden winds or carrying Robin’s pack. Sat here a day earlier when a gale was ripping through at an average of 35mph and gusting to twice that, it may have been a different story, but my long-bodied, yaw-suppressing, high-sided, tough hulled Yak inspires confidence, even without the spray skirt.
fullyakThe price you pay is weight and bulk. Ready to paddle, at 3.1kg with seats, heel pad, pack attach and lead,plus other straps and some mini krabs, my boat is 4.5 times heavier than the Supai as tested, and even more bulky when you add in the blow bag, skirt and repair kit: the red bag shown right.
Robin slowly waddled over to the south edge of the loch and got out with care before pulling the plug and rolling it up. As on any inflatable, the floor is vulnerable and we discussed ways of getting round this. One problem is the Supai’s floor glues to the hull ring above the lowest points in the hull tubes which means the undersides of the hull are actually lower than the floor (until you sit in it on the water). Using a thicker floor panel supai20won’t eliminate all possible wear. Robin is a versatile home-fabricator (as his B&Q paddle proves) and we decided the least invasive way of protecting the entire underside – hull and floor – would be to string a sheet of whatever you like from the peripheral half-inch hull seam (the seven reinforced tabs not being quite enough to do the job). No messy, irreversible, crease-inducing gluing required, just a line of holes along the seam plus a drawstring. Pre-emptive protection is something I’ve done to my Alpackas’ ballistic nylon floor and although it won’t look too neat, a floor sheet would enhance the less robust Supai’s undercarriage, despite a weight penalty.

Our conclusion
He may have got used to it over time, but the Supai felt too skimpy for 80-kilo Robin. Ill-dressed on the day and over-fed in general, I didn’t even try to get in. Build quality is great and the fabric I could live with; it’s much better than slackraft PVC and the extra care needed in handling is well worth the weight saving over an Alpacka. Factoring in experience, company (support), weather conditions and operator weight, the Supai felt right on the limit. Initially you’re reluctant to paddle normally for fear of swamping which could turn exponential. Alongside a Yak it’s a pretty slow too, although I don’t think that’s a flaw. My Yak is slower than my IK which in turn is slower than … As long as it makes progress, a boat is as fast as it is.

alpacka-scoutAlpacka’s Scout might be a fairer comparison with the Flatwater II. According to Alpacka stats it weighs 1450g, is 4.5cm narrower, 2cm shorter inside and 26cm longer overall, while costing at least $200 more in the US. That still puts the Supai well in the ballpark on weight and cost.
Although it looks to have been designed for the canyon lands of southwest USA, for the lighter paddler the Supai could a great packraft for less predictable Scottish conditions involving short, flatwater crossings. The negligible weight really opens out the options and means you don’t have to get too fanatical about the rest of your gear which can translate into greater comfort.
supai11I knew this even before I saw the boat, but what I’d love to see is a Flatwater XXL more closely matching my Yak’s (or my) size. I’d happily trade the extra 8cm of width the Supai has at the hips for fatter and higher tubes all round, plus another 10cm added to interior length. It’s hard to think that would add up to much more than a kilo overall, but would reward the portlier or overnight-equipped paddler with a more versatile boat able to deal with dodgier conditions. Let’s hope this is part of Supai’s game plan.

Photos also by Tim Evans who writes:

I got interested in packable boats as I love both walking and being on the water. My first major trip was in an Alpacka Yak from Whistler to VancouverI hiked for 2 days, paddled the Cheakamus River for a day (with some easy whitewater), then paddled 24 miles of ocean inlet back to Vancouver. This trip was only possible because of the packraft. Then I bought a Supai and did 35km through a lake system north of Vancouver that included a number of portages. I saw a pair with a canoe which they pushed on a trolley through the portages with 200lbs of gear. It took them hours to go a few km. I did the 4-day trip with 16lbs of gear including food, just to see if it could be done (it can). I could have jogged through the portages with my little boat tucked under my arm. The Supai was a light as it gets, but SLOW for any sort of distance.

Read about Tim’s superlight IK here.
