Category Archives: IK & Packraft Sailing

Experiments and Experiences

More kayak disc sailing

The IK & packraft sail Index Page

Unbranded windsail update 2016: the 3mm-thick glass fibre rod snapped. I bought another length for a tenner. It felt more flexible but within a couple of days that broke in two places too. If I run 3mm rod doubled up I presume the bending forces will be the same, but if I run thicker rod I presume it won’t fold down three times to the compact 30cm diametre disc.
Looking again at the original WindPaddle, it does seem much of the cost is explained by the ‘proprietary’ composite rod they use, and there seem few easily found online reports of breakages. Prices seem to have dropped quite a lot too (as they have for the ebay knock offs). Could it be you get what you pay for after all? It’s a lesson so often learned here at IK&P!

sai01
sai-disc

The other evening I hooked my old home-made disc sail onto the Grabner’s bow (left and above) and took it out on a loch to remind myself that it wasn’t really that good. As before, I found it difficult to get a good run before it flapped out or otherwise lost its drive.
My Pacific Action V-sail will work better, but fitting that to the Amigo may require more D-rings. I like the compactness and simplicity of a disc sail, but it was suggested that dishing like a bowl was the key to holding the wind and maintaining steady progress, even if it may be less effective tacking across the wind.

Parachutai

Sounds plausible and WindPaddles are clearly made like that for a reason. Since then it occurred to me that’s why classic ‘descending’ parachutes (‘reverse’ sails) are bowls and not flatter discs which would shoot across the sky. Before I set about recutting my disc into a bowl shape I checked WP prices on ebay and spotted what looked like a knock-off: ‘Canoe sail kayak sail wind sail‘, now just £15 delivered. Cheaper than sewing and at 115cm deployed, it was midway in size between WP’s Adventure which at the time was selling for no less than £155 in the UK (now about half that). Someone assure me that a WindPaddle costs even a fiver to make in China, but see top of the page.

And better still, the no-name windbag folds down into three hoops of just over a foot in diameter (above left). Plus there’s an elastic hoop to keep it like that and a carry bag for the long walk back to the van. Out of that bag, the only changes I made were to replace the too-short control strings with my tape off the red sail which I find easier to handle. I reassigned a sling to hook the sail’s base to a floor D-ring back from the bow (above left). That was already fitted and was the only adaption I needed to mount the sail to the Grabner.

sai03

The day before, with the visiting Nimbus family we’d paddled round the Ristol isles. Over lunch on Ristol beach I took my new sail for a burn up. First time out, not bad at all. I got a steady run and up to 3.9 mph on a breeze of no more than 15 mph and with very little faffing. The prospects were good. More wind was needed.

sai12

Incidentally, on the beach I noticed how very, very much unlike a sea kayak the Amigo really is. Alongside my old Incept, let alone the lethal Scorchio HV (right), the red boat looked like one of those inflatable kayaks you read about, except it happened to be made from bomb-proof hypalon and pumped up like a basketball.

sai-mulla

Earlier on, coming round the southwest corner of Eilean Mullagrach, (left), the swell bouncing off the cliffs and crashing over outer reefs looked intimidating. Though we all managed fine, it was everyone for themselves. With heads bent to the task, the comparative speeds of our four boats was clear to see. Way out ahead and longer than your average four-door car: the cheddar-coloured P&H cheese cutter. No far behind, 12-year-old Boy Nimbus darted along in his 12-foot Carolina (later I GPS’d him at 6mph, same as the P&H). Further back Mama Nimbus and little Nima in the K40, all hands on deck. And out back the Grabner hypalon clog – splish-splosh, splish-splosh Slap. Checking the GPS data the speeds weren’t so bad, it’s just that in the rough the hardshells cut through some 30% quicker.

sai-2bots

A few days later the Solar was stacked on the Amigo (right) and I realised it was only a foot or so longer than the Gumotex. In that case the Grabner does pretty well for a 12-foot four-, 31-inch kayak that hauls two paddlers.
Back to the sailing. Next day winds were forecast at over 25 mph (right) but as it was warm and only a 5-minute drive to a Loch Vatachan, it was worth a crack.

sai-splasher

A short pre-paddle suggested my cheapo windsail would probably get ripped off and blown away, or else see me roll off the back of the kayak as it shot away from under me liked a snatched tablecloth. Upwind I couldn’t exceed 2 mph (left), but skimmed downwind at up to 5.5 mph providing I kept the stern right on the wind. And while I was out here, side-on to the one-foot fetch the Amigo felt secure, so not a completely wasted outing. I’d never set out to paddle in such conditions normally (actually I did once), let alone try sailing (actually I had once) so I called it off. Later, Ardmair weather station confirmed the wind had been howling at a steady 35 and gusting to nearly 50 mph.

sai-boats

We all ‘yaked over to Tanera Mor one afternoon; three IKs and two SinKs. I realised I’d never actually walked up to the 124-m summit of Tanera Mor for a look around.
Up on top a string of islets lead to the twin humps of Priest Island, 4.5 miles in a straight line (right). It was a ten-mile round trip I’ve mentioned earlier but may be beyond reach this time round.

sai-tansouth


Paddling back from the island, Mama Nim found my old Incept had picked up another pin-prick hole in the side. Wtf is happening to the K40? It’s a lot better than the armchair -wide Sevy they were borrowing before, but three holes in four outings? And it gets worse. On leaving the island the wind dropped to nothing so sailing was off. Instead, we were plagued by sea midges which rise from their lairs as soon as the wind turns its back.
Another day and a healthy northerly forecast at 10mph on the BBC which might mean 15 in real terms. I set off with Nimbus in his Scorpio ‘PK’ (plastic coffin) for a look at Tanera Beg’s arch he’d missed on previous visits. It’s a nice arch; we passed it a couple of weeks back, two-up in the Amigo.

sai-keens


Once clear of Old Dornie I threw the sail out and trotted along at 3.5 mph which won’t be giving me any nosebleeds but I suppose must be classified as progress. At least I found a good way of stashing the sail. Seeing as it’s right out on the bow, refolding it down to three hoops isn’t practical on the water without help or taking risks. But I could just pull it back and tuck the squidged sail under my feet and between my legs (above). Down here there’s little risk of it self-deploying and jumping overboard to become a most unwelcome sea anchor, but it can be thrown up in a jiffy to catch a breeze, just as with the PA.

sai-padd

Once we got to the two Taneras’ In-Between islands the wind remained but the waves were blocked so I threw out the air bag and trickled along again at about 3.5mph again. Then it occurred to me I could hold the sail leash in my teeth and paddle. That worked well too, getting on for 5 mph but without the paddling effort to make that speed unaided. Plus it felt better than having the sail hooked to my pfd and stopped me talking unnecessarily.

sai-archers
sai-calmacer

Once past the In Betweens we crossed over to the arch but found we were a metre short of water. Still, high or low water it’s a great mini-destination some three miles out of Old Dornie.
The easy part was over; it was going to be a solid old hack back into the wind for Old Dornie. As we turned we were a little perturbed by what looked like the  Stornoway ferry heading right at us. I’m sure it never came this far north, was the captain asleep at the wheel or taking a deeper channel on the spring tide?

sai-breaker

At the last minute the CalMac turned away and a calamity was averted. A few minutes later its wake rolled in, breaking a couple of feet high just as we  passed a reef. It looked like a good picture so I sent Nimbus back for a shot (above) but by then the best of the surf had passed. If that was the swell kicked up by the ferry from a mile away and before it hit full speed in the Minch then I’m glad we keep our distance.

blofie

Time to put the camera away and knuckle down for an hour’s bow slapping to Old Dornie. As I’ve observed before in such conditions, Nimbus in his SinK paddled like he was stroking his favourite cat, gliding through the waves in a seemingly relaxed procession. Me? I was loading 16 tons and what did I get? Slipping back further and deeper in bilge.
Still, not alone for a change was less unnerving and I quite like a good work-out on familiar terrain. You dial in the effort you know you can sustain for the duration and progress at whatever speed that delivers. From the graph below that added up to about 2.5 with occasional surges to 3 mph when my technique briefly hit form. The P&H PK seemed to hold a steady 3+mph without trying.

sai-splarsh


The wind had failed to live up to the forecast promise of dropping around 6pm and out in the mid-channel a few white tops developed; for me a warning sign it’s approaching IK limits. I will speculate that I shipped less water than I would have in the Sunny which is a similar type of IK. Partly because of the Amigo’s upswept bow that front or rear, doesn’t seem to be as much of a wind catcher as it looks. And perhaps too because the boat doesn’t bend with the swell.

In fact it was fun slapping the fat bow against the oncoming waves as I slowly hauled my way closer to Dornie. Old Man Nimbus can read wind speeds like a Tubu hunter reads the sands. He estimated it was blowing at 8m/sec which in English translates to 20mph. I’d have guessed a bit less, as with the spring tide at full flow against it, it didn’t seem too much in an IK (as long as land appeared close by). As we neared the harbour a couple of other SinKs slinked by, tucked right under the shore, out of the wind. Get out here you cowards!

angleferry

No Name wind sail
My conclusion of the no-name wind sail? It’s a WindPaddle at the right price. Easy to fit to my boat and doubtless many others, easy to temporarily stash on the move and probably easy to repair. And easy to steer too; pull left to go left, usually. With the window pane it’s much better than my home-made flat disc, plus it’s less bulky and complex than a V-sail, even if a V will give you nearly 90° reach either side of the wind.

ferryspd


Surprisingly I haven’t found the lack of a rudder an impediment with the Grabner. Though there’s a bit less directional control, at the typical sub-4 mph speeds you can drag a hand or a paddle blade to bring the nose around. And interestingly, providing you’re close to the wind and holding a steady course, the sail worked pretty well when paddling with the leash in my teeth like the 3.30 line up at Cheltenham. I can’t say I ever managed paddling with the Pacific Action on the Incept for long before it flapped out. Plus there’s plenty of scope for hooking up some self-jamming cleats (more here) like I ran on the Incept.
Above all, the no-name air scoop is great value for money for the performance it delivers. For thirty quid it wouldn’t be worth making your own. Next job: see how the little Alpacka handles when yanked along by the wind sail.

See update, top of the page.

The A to Z of Inflatable Kayaks

a2zik

halforts
lidl

Inflatable kayaks are a bit like mountain bikes. You can buy a blinged-up piece of overweight junk with ‘full suspension’ from a superstore for under a hundred quid. Or, if you’re serious about your cycling fun you can buy something decent that’ll be a joy to own and ride.

Continue reading…

Pacific Action V-sail revisited

Packboat sailing main page

Windy but warm and dry thanks for asking – a good afternoon to take the IK out sailing. I’ve not done that since Ningaloo last September (left) when I was blown away so to speak, but not in a good way.
Even before then I can’t say I’d got the hang of the Pacific Action V-sail which should add up to either hurtling from crest to crest with all hands on deck – or kicking back and getting a free ride while looking around at 3mph. Both are good fun but neither scenario seems to last more than a minute for me.

Remounting the V-sail to the K40 was easy. I clipped the front ‘sail-hoisting’ bungie about 8 inches further forward, right out on the boat’s nose using a loop of string and tape (right) as opposed to using the boat’s lift handle-ring. Fixed here it ought to help keep the sail up when pulled down low to one side by increasing the angle and distance from the sail’s feet. It’s an idea we came up with in Australia in an effort to make the K40 controllable in the strong winds.

Winds today (left, from 3pm) weren’t quite as strong as WA but were getting there. And anyway, I was out on small lochs with no rudder-lifting ocean swell to deal with – another reason we thought the K40 got squirrely in strong winds out in WA. The K40s large draught but low weight acted like a sail of it’s own, weathercocking the boat.
To reacquaint myself, I first took a spin on the smaller Loch Raa. I’m never really sure what I’m doing so just try various angles and approaches until the kayak catches the wind. I’m told that sailing directly downwind with the sail fully upright is less efficient (or is that with regular, fixed-mast sails?). With the PA you can get a good speed for a while, but soon the sail starts rocking violently from side to side as it sheds the excess blast – my strong recollection from Ningaloo. I assume that’s just a sign of the sail exceeding it’s speed limit, though I think Jeff’s hardshell did it less.

Off the wind about 45° and up to 90- or even 100° (ie; slightly upwind) seems more stable but slower, with the sail cranked down low to one side. But even then a consistent speed or direction seems hard to maintain for long. Is it my poor technique, the design of the sail when applied to my IK, or just an aspect of gusting and shifting wind? As it was I felt the unloaded boat was rather light, though in Ozzie last September 20+ kilos of ballast didn’t help much either.

Big sailboats and windsurfers seem to manage OK, but it seems hard to get a smooth, steady run while sat back with the cleated-off sail doing the work. Usually I’m yanking hard on the rudder to get in line, or have handfuls of lines trying to trim the sail for best effect. The tiny ‘finger-and-thumb’ cleats are just too fiddly to use in a hurry or mild panic, and often require two hands to release the jam. I wonder if hand-sized cleats exist for the thin cord, or some better device all round? Something like a sliding tube you could grab, but with a release button, a bit like a mountaineering jumar (left).

Even then, on seeing the speed readings (above), it surprised me how fast I could hack into the wind at 2.5–3mph, admittedly with some effort (needed to keep the kayak pointed ahead). Coming back with the big sail I only got over 5mph a couple of times, and often moved barely more than upwind, although using much less energy of course.

I came across this image of a Micronesian waharek boat newly built on an ancient design. Looks like a big V-sail to me but crucially, it has an outrigger.


After crisscrossing Loch Raa a few times (above right), I went around the corner onto Loch Osgaig. Out in the open and with the wind bouncing off nearby Stac mountain, there should be room enough to get some speed up, providing I could hold on.

I set off and sliced the waves as best I could and stuck at it until I got opposite the small plantation. Here I stowed the paddle securely, got blown round and unfurled the v-sail, ready to snatch it back down should it all be more than I could handle. In fact, there were only a couple of hairy moments As you can see from the speed graph (right), my paddle out was pretty steady and straight, but under sail, speeds and direction were all over the place. A couple of times either a gust or the optimal line saw the boat fly at along at over 5mph (left), but it never lasted.

saijeff

It does make me wonder what the PA sail is good for on my K40. In winds of over 15mph it seems hard work to maintain. Is it an inherent flaw of a lose, articulated mast – and one whose feet are not pressing directly onto a solid hardshell hull (I use a plastic dinner plate to spread the load/reduce wear). The fact is, Jeff managed fine on Ningaloo (right), ripping along in a boat that was four times heavier than the Incept. And in Shark Bay a few years earlier in the same tandem tanker, he was towing me in my Gumboat.

A 10-15 mph breeze does often correspond to a nice steady sail, but that does seem a rather narrow margin of operation – something I recall someone else saying to me about V sails. I think it’s a combination of more practice required, hampered by the fact I’m in a light, buoyant, flaccid-chined IK. It makes me wonder if the WindPaddle is worth another look (it was and I did), though I’m fairly sure the PA V-sail is more versatile; I doubt you could ride at 90°+ to the wind with the deeply dished WindPaddle. Another good thing about the PA is that it’s out of the way when down but dead easy and fast to deploy or stash. Just throw it up and see if it takes to the wind. Out this time I also felt that the thigh straps were particularly useful when edging the boat against the gusts.

Kayaking Ningaloo – Part 2 (Incept K40)

Part 1 is here.
Gallery at the bottom of the page.

After a spell of snorkeling in Coral Bay and reading in Exmouth, I drove round to the ocean side of the Cape and met up with Jeff and Sharon near Yardie Creek in the Cape Range National Park. Later they told me they’d had their camp swamped early one morning by the tide, but had an exhilarating run around Point Cloates dodging humpback whales and covered up to 55km a day, all under sail.

But all was not well with our ill-defined status in the national park. Most visitors arrive by car or tour bus and book their camp sites well in advance if staying a few days. Wild camping is not on, but as I’d discovered to my surprise in Exmouth, all of Cape Range’s few campsites were booked for days in advance and occupied for weeks, with newcomers queuing from 8am at the park entry gate near Tantabiddi for any vacancies. Rocking up off the sea in kayaks was highly irregular and Jeff and Sharon had been given a bollocking by the head ranger who reluctantly negotiated a fixed itinerary for us to follow through the park, ranging from 4- to 20kms a day, until we exited the park at Tantabiddi.

While waiting for the other two to arrive, I took a quick scoot in my underused boat up Yardie Creek gorge (above), a 2km cleft in the otherwise flat coastline. Official boat cruises run up here to spot bat-eared rock wombats, a trip that I must have done in my time when updating the guidebook. But even running Yardie in my own boat, I thought by WA standards this was a long drive to a very ordinary gorge. Send them off to Karajini or the Gibb River Road and leave Yardie to the speckle-chinned wallabies.

I gave my problematic V-sail another spin to remind myself it had not become a complete flop. With a more secure fixture of the mast foot straps and the elastic cord positioned right on the boat’s black nose, it worked well enough in the light breeze, but could still do with some sort of bowsprit (sticky-out front pole) to get the elastic clip still further forward – a solution that’s easier than making alternative mounts for the sails masts.

I set off to Pilgramunna Camp where a note from Jeff explained that an extramural pitch had been allocated for us boat people. Months earlier I’d spent ages on the DEC website looking for kayak touring regulations in Cape Range but had found nothing and so concluded it was the same ‘come through but leave no trace’ deal as at Cape Peron down at Shark Bay.
Turns out there are no formal regs for kayak tourers visiting the park as it seems only a few kayak parties pass through each year. But as the park is about 60km long along the shore, you’re going to need at least two nights in the half dozen official campsites which mostly probably need to be booked in advance in the more tolerable seasons. That’s something that is difficult to plan for if coming up from Coral Bay, nearly 100km away.

With our pitch allocated, I set off in my kayak to meet up with Jeff and Sharon coming up from the south. We were soon reunited on the water (above) and shared the stories of our separation. They were low on food so back at the camp were pleased to tuck into a cake Sharon had baked for the trip and which I’d managed to resist eating during my days hanging out.

Early next morning we were all set to complete the less demanding two-day run along the reef up to Tantabiddi, but now northeasterlies turned on us as the back end of a high pressure system moved east over the continent. At least these were conditions I knew the K40 and I could handle, right up to the point when our pace progress dropped to zero.

The winds scuppered any reef viewing opportunities off the boats and a momentary pause in paddling effort saw the boats stall and drift backwards at least as fast as we could move forwards. But here at least were the fabulous azure lagoons and shell-white sands of Ningaloo.

Just before Turquoise Bay we stopped for a snack at which time Jeff took a quick scoot in my empty Incept . He proclaimed my boat was light and fast but my PA sail tension was still too slack or the mast-to-elastic clip distance too short. That was something I’d thought of and re-rigged the front tensioner further forward on the nose of the boat, though I may try the bowsprit idea mentioned above.

That was academic in the current headwinds so Jeff led the boats off on a lead while Sharon and I took advantage of a current the ran along the point leading into Turquoise Bay created by the lagoon filling with overspilled surf which ran out as a riptide through a gap in  the reef. Compared to Coral Bay, there were many more soft corals here along with all the usual fishes. Coral Bay coral gardens got trashed by a cyclone a few years back.

That done we hacked on northwards across Turquoise Bay, busy with weekend day trippers, and occasionally took to walking out boats in the shallows as we’d done in Shark Bay. As we did so we passed a couple of stocky reef sharks as well as several turtles and rays.

By the late afternoon it was clear that after nearly a week at sea, Jeff and Sharon didn’t have the puff to make it to our pre-ordained camp in the portly tandem, so we pulled in on a beach for a much more satisfying wild camp and a great feed laid on by Sharon from a food cache we’d retrieved earlier in the day. To avert any alarm or searches we left a phone message with the head ranger. As the fire died down we dozed off at 8pm and the wind dropped off, promising a good night’s sleep. Its howling was replaced by the distant roar of surf breaking over the reef.

Early next morning we got the break we were hoping for: near still conditions. After forensically tidying up the camp, we headed out towards the surf line and finally had a chance to enjoy a little of what we’d come here for: gliding serenely over the reef just a few feet below, past fishes, sharks, turtles and rays. No need for a mask or glass-bottomed boat today, it was all laid out below us for an hour and a half until the north winds returned us to business as usual.

Mesa Camp came and went, with a report passed to the head ranger that we were breaking with his proscribed itinerary and making our way out of the park that day. Turtles dashed all about as we nosed into Mangrove Bay, a welcome change from the unending string of scrubby low dunes that lined the shore all the way up from Coral Bay, if not Perth itself.

Another spell of wading brought us finally to Tantabiddi boat ramp by which time I’d divined a new paddling technique probably known to all: pushing off the mushy inflatable’s footrests actually enabled a rigid torso rotation which notably increased speed for little extra effort. With energy to spare after only a day or two’s paddling, at times I was even inching past the tandem until we nudged ashore at the ramp. Jeff and Sharon performed a ‘paddle high five’ after completing their challenging 150-km run up from Coral Bay, most of it alone.

The boats and gear got hosed down at the fish station while I hitched back down to Pilgramunna to retrieve the van. It was nearly dark by the time I arrived and I must have spotted and dodged up to 100 ‘roos on the 40-km drive back. I’ve never seen so many kangaroos. The park was infested with bounding marsupials: ‘Ningaroo’ they should call it.

So, I ran out of easy conditions for a good sea paddle through Ningaloo; something I suspected might happen even before I left the UK. But I wasn’t too bothered. I got a couple of days in plus that lovely calm morning and knew that a meaty packrafting adventure lay another 1000 clicks up the road in the Kimberley (see map below). I got the impression from Jeff and Sharon that, apart from the humpbacks and not least the satisfaction of having kayaked the entire way from Coral Bay to Tantabiddi, I hadn’t missed that much. Unlike Shark Bay, here it was the reef that was special, best appreciated in calm conditions or on the end of a snorkel. Otherwise, you might as well be battling the winds anywhere along the WA coast.


I can’t be sure I’d reached the limit of the K40 (as described in part 1), but until I get more experience I’d certainly reached my limits trying to handle the kayak in very windy conditions I’d not normally tackle back in the UK. That still leaves a lot of easy sea kayaking and fun rivers to do yet.



Kayaking Ningaloo – Part 1 (Incept K40)

After a great paddle in Shark Bay with Jeff and Sharon a few years ago, we’d vowed to try the more exposed transit of the Ningaloo Reef, from the small resort of Coral Bay, north along the west side of the Northwest Cape through Cape Range NP as far as Tantabiddi boat ramp. All up about 150 kilometres or a week’s paddling.
The entire coast of WA is bare, windy and exposed to swells raised by storms in the restless Southern Ocean, with few settlements and little shelter or natural sources of freshwater to speak of. Only the extensive lagoon of Shark Bay and the reef-protected shoreline of the Northwest Cape provide potentially interesting sea kayaking, sheltered from the daily sea breeze, even if access to fresh water is still a problem.

What makes Ningaloo special is that the continental shelf is relatively close to the shore compared to the northwest coast up towards the Timor Sea. This fact, as much as the presence of the reef, explains the unusual diversity of marine life which led to the marine park’s UNESCO status. Small fish, turtles, rays, small sharks and dolphins live or visit the lagoons between the main reef’ and the shore, while bigger creatures right up to humpback whales, tiger sharks and not least the whale sharks for which Ningaloo has become famous, usually feed along the outside edge.

After a 1200-km overnight drive from Perth, we arrived at the Coral Bay (CB) where Jeff’s first comment on easing himself out of the driving seat was ‘Jee-zus, look at the swell out there!’. The reef lies just below the surface a kilometre offshore here, and the Indian Ocean breaks on it unceasingly, forming a glaring band if ice-white surf, at times thrown 2-3 metres into the air. That wasn’t an undue worry for us as we were planning on staying well inside the near-continuous Reef, but the winds were another matter.

Following weather reports over the preceding weeks I was beginning to wonder if September (early spring) such a good time after all. Asking around, many said a month earlier (as we’d been at Shark Bay) would have been fine – or May, or in high summer between cyclones. Everyone had their own suggestions, but the fact was right now the forecast for the next week (left) was 20 to 30-knot winds from the east or southeast, with gusts half as much again. As a result all fishing and tourist boat charters were cancelled out of Coral Bay.

Sounds grim unless you’re into tough conditions, but the good thing about following the Ningaloo is that it’s easy to bail out and cross the low coastal dunes to a rough 4×4 track that runs just inshore. A few cars ought to pass along it each day, so I figured even though I’d never go out in an F5 or 6 in the UK (where the seas are bigger, the skies greyer and the water much colder), here with reliably sunny 30°C days I’d give it a go as we’d never be far from the shore. We’d considered starting halfway up the coast at Ningaloo Homestead and just doing the less exposed northern stage, but the other two were keen to do the full run from Coral Bay (left). And anyway, getting Jeff’s van in and out along the Homestead’s corrugated access track with his 55-kg Perception kayak on the roof was not ideal.

Sunday Jeff and Sharon drove out to leave caches of food and water at the Homestead and another point up in the Cape Range park, while I investigated logging our route plan and details with anyone who was interested. Turns out that was a short list as most marine activity in Coral Bay was concerned with nipping out through the reef in motor boats for the day of fishing. Kayaking beyond the Bay itself was unknown and I was told within a day we’d be out of range from the local volunteer rescue services anyway. But we had my sat phone, Jeff had a VHF, plus a chart and we had a GPS each. The weather wouldn’t suddenly get much worse; it would be challenging from the start, so we knew what we were taking on.

Monday 6am and Jeff was raring to go; no time for breakfast – straight to the beach from where our mission that day was to cover 40 clicks, even although we had 9 days to cover the other 110 kms to Tantabiddi during which time we planned to linger and enjoy some reef exploring.

We loaded the boats on the shore, set off and flicked up our Pacific Action V-sails. Behind us, a curious crowd of early morning dog walkers had gathered while I struggled to follow a straight line across windy Batemans Bay (‘Coral Bay’). The sea was flat enough but the Incept seemed hard to control as the sail flapped or swayed violently from side to side. I tried to imitate the sail position Jeff was running on his big tandem, but soon even he reckoned it was already too windy to use the sails, so we pulled them in and paddled around Point Maud into the big scoop of coastline that leads north some 60km to Point Cloates below the Ningaloo sheep station.


The wind still blew offshore at this time which helped flatten the seas just as Jeff predicted, but soon a mile-long gap in the reef let the ocean swell through from the left. It rolled beneath us harmlessly and crashed with occasional fury on the sandy beach far to our right. As the morning progressed we tried sailing again. With years of experience and a well set-up boat, Jeff was much more proficient at this, but during the stronger gusts I was again struggling to get to grips with the K40. Where was the 10kph+ rush the PA sail had promised? Testing it in Scotland had hinted at this potential, but now the winds were an order of magnitude greater. One problem was the force of the wind had loosened and pushed my mast feet forward, so lessening the all-important elastic tension which keeps the sail pulled upright, especially at lower angles. At one point Jeff leaned over and tightened the straps (and later I revised the straps to link directly to a couple of lugs) but as the hours passed I could feel myself losing confidence in my boat, too busy trying to control it or keeping up to even grab a drink, take photos or just look around.

At the sandy Bruboodjoo Point we pulled in for a snack after five hours paddling. Unknown to us, there was a camp here called Nine Mile, occupied by self-sufficient recreational fishermen. Having already covered 20kms, I wasn’t feeling reassured about what lay ahead, when a woman bathing nearby confirmed that the winds were set to get stronger through the week.

We set off again into what was now a strong southwesterly – the daily ‘sea breeze’ which rolls in in late morning along the entire west Australian coast and is known as the soothing ‘Fremantle Doctor’ down in Perth. In this stronger wind I was even less able to sail as steadily as the tandem. We had tried long and short line towing (rather than rafting up alongside) but under sail or not, the bobbing Incept was all over the place, fouling the Perception’s rudder and at times pulling me over or burying the bow. After a bit of that I decided to revert to paddling, but by now even doing that in a straight line was a struggle.

At the time I couldn’t pin down the source of the difficulty, but I’d probably never been out in such winds. Jeff thought my rudder was ineffective or not articulating fully, but it was doing as well as normal for a mushy foot linkage system with a bit of rudder cord drag due to the packed payload. Could the rudder be too small or short to operate with the sail? Unlikely. Later I wondered if I may have reached the operational limits of the wind-prone K40 – at least when combined with my rudimentary skills. My boat was about as high above the water as Jeff’s, but with much less weight below, and at 17kg, was less than a third of the tandem’s weight. And even with a rudder, it still lacked the sharply defined stern and bow ‘keel-edges’ of a hardshell to enable it to cut and hold a line in the water against back- or sidewinds. As it was, it was a bit like trying to ice skate in slippers; you can work up some speed sure, but directional control is minimal.

This blobby shape is an inevitable consequence of inflatable kayak design that’s difficult to get around until full dropstich came on the scene. The result – with sail or just paddling – was that the light kayak’s hull itself was as prone to back/side winds as the sail, and so weathercocked (back end coming round) as I zig-zagged inefficiently to try and counteract it. Weathercocking is not unique to IKs of course. and I don’t think the boat’s trim (load level – about 30kg) was off – there was 10kg of water right at the stern. It’s just that in the current conditions the K40’s light weight, buoyancy, rounded hull and high sides conspired to push it about on the water, even if those high sides and the boat’s innate rigidity greatly helped limit swamping compared to the bendy Gumotex Sunny in Shark Bay a few years ago. The sail needed more tension to stay up when pulled down low, but that was easy to remedy and I noticed also occurred on the Perception where Sharon had to hold up the upper mast at times.

deeptr

I can’t be certain those observations about the boat’s handling are correct, and perseverance may have overcome them, but even when the K40 had sailed steadily in less strong winds earlier that day, it was still much slower than Jeff’s 20-foot-long tandem whalesharkboat with its bigger 2.2m PA sail. I assumed weights and hull profiles of the two boats would have matched up, but as well as being a hardshell, length has a lot to do with it, so instead of keeping pace with J&S in my new, faster, sail-equipped boat, even when I sailed well I was left just as far behind as I’d been a few years ago paddling the Sunny in Shark Bay. It was all going Pete Tong and I foresaw this was how those stories in Sea Kayaker ~ Deep Trouble begin: “Jeff, Sharon and Chris left Coral Bay in clear conditions but with strong offshore winds forecast. They were equipped with blah blah but had no blah…
As the tandem surged on I sponged out the swill taken on by the towing and a bloke in an alloy dinghy or ‘tinny’ came over to ask if I was OK. It was an encounter that was to pay off soon. I set off again, paddling with the odd small wave breaking from behind. The tandem was fast becoming a speck up ahead. It was decision time because at that moment, without a chance to talk over options with the other two, getting widely separated like this didn’t seem like a good idea. After the unexpected Nine Mile Camp, there was nothing till the Homestead from where it would be more awkward to bail out if I’d had my fill by then. I looked back at the Camp, now a couple of clicks behind. Up ahead the tandem’s sail was nearly as far off with no sign of them slowing down. I decided I’d pull in. Hopefully, the other two would notice that, stop so I could catch up and get the van keys and rejoin them on the less exposed waters north of Yardie Creek in a few days time.

‘Thank God that’s over’ I remarked with relief as I landed and lifted the boat over the exposed coral slabs marking the tide line along the beach. It was about 2pm. I grabbed a bottle of water and set off north along the coast to meet up with the J&S who I was sure would do likewise soon. An hour later I reached a very conspicuous zone boundary post just before a small headland – an obvious place to wait, I thought. I climbed onto the structure and scanned the beach about a kilometre ahead. Was that a boat or just a rock? There was no sign of the distinctive PA sail and after 15 minutes nothing had moved so I decided that they had shot on ahead. Short of something holing my boat, there was no reason for them to think I couldn’t paddle ashore and they knew I had water, food and comms and so could work it all out.

I returned to the boat, finding a handy half-full water bottle on the way, and paddled slowly south into the wind for an hour and a half back to the scattered collection of caravans at Nine Mile. Over the dune I walked to the nearest van where an Australian flag curled and slapped in the wind.

Hello, is this immigration?” I said with a grin to the old guy, mimicking one of the Asian boat people who frequently beach themselves on WA’s shore.
What?”
I saw the flag and thought this was immigration

Clearly my joke was going down like a lead lure.
Oh that, I just use it to see where the wind’s blowin’ from.”
I see.
Pardon me.

Jim was one of the many retired Australians who now far outnumber backpackers up north, as they seek to escape WA’s southern winter. Coral Bay’s caravan parks were full of them and, as I was to find out soon, every site in Cape Range NP up ahead was full of ‘grey nomads’ too. Hardier and better-equipped types based themselves for longer periods at zero-facility sheep station sites like Nine Mile, where rents were cheaper and stays unlimited. Even then, Jim (the guy in the tinny who’d asked if I was OK, earlier) told me that normally Nine Mile would have had 60 vans parked up. The unseasonably strong winds over the past couple of weeks had driven off most of them, leaving just a dozen diehards. With summer on the way and fishing in such conditions difficult in a tinny, Jim was about to head south himself.

I explained my situation and asked whether he had a radio to call Ningaloo Homestead. Many vehicles have these in the north. Jeff had made an arrangement to check in with the Homestead on his untried VHF that evening, so could get my message and leave the van keys there. Jim only had a CB, but he did have Ningaloo’s phone number. He expressed repeated surprise that the other two hadn’t waited once I was so far behind, but I figured they’d recognised I’d had my fill and bailed.

I tramped back to the boat as the sun sank and on the satphone explained the situation to Jane at the Homestead who thankfully got it all in one take. They’d experienced worse kayak dramas before. She’d pass on my request for keys when Jeff turned up there next day to retrieve a cache of food and water he’d left with them just before we’d set off.

Long story short
Jeff and Sharon had stopped just a few kilometres ahead of the point I’d walked to and waited for me till next morning to turn up. When I hadn’t, Jeff walked back to Nine Mile, found out what happened, walked back and continued on towards the Homestead, arriving the next day.
Separated by 10-15kms that night, we both had rough nights of tent-flattening winds after which the site host at Nine Mile offered to drive me back to Coral Bay where he was heading anyway with his laundry. At the caravan park the host and I set to the van doors with coathangers and zip ties until they yielded. Though we couldn’t get past the immobiliser to hotwire it, the van became a handy base while I worked on a new plan.

By now on the notice boards in town there were Strong Wind Warnings for entire northwest coast of WA. I updated our status with the DEC (parks authority) and, not a little anxious myself now after more calls to the Homestead, a day later finally spoke with Jeff. He apologised for not stopping earlier – I suspect the sailing was just too good and I too had been looking forward to the rush of being batted up the coast with my feet up. His VHF didn’t get through and his walk to Nine Mile explained the day’s delay in getting to the Homestead.

With that sorted out, all that remained for me was to wander around the Coral Bay campground eyeing up likely candidates until I succeeded in persuading a young Brit backpacker that for fuel and 50 bucks, it would be an awesome adventure to drive me 120kms to the Homestead and back in his clapped-out Suzuki banger.

If Jeff’s $1500 van was rough, Rory’s 20-year-old Suzuki Swift truly had three wheels in the scrapheap. Even he admitted it would probably not make it to Darwin as he and his mates had planned. The CV joints clattered like a football rattle and I’m sure the 60 clicks of corrugations along the homestead access track brought the Suzuki’s imminent Big Bang forward a few weeks.

At the Homestead Jane confided that the southern bay up to Point Cloates was indeed the more exposed ‘open water’ stage of the Ningaloo passage and the wind had certainly come up on Monday afternoon. When it blew like that for ten days at a time, she admitted it drove her nuts. But all this as least boded well for the more sheltered northern section of the paddle in a few days time. The car got us back to Coral Bay where I started the van up and headed north to Exmouth, planning to meet J&S at Yardie Creek in three days time.

Part II and a short video

Kayak and packraft sails

As of early 2021 it seems WindPaddle.com are no longer in business

You may have read in the Shark Bay story what a relief it was to turn into the wind at Cape Peron, get Jeff to flick up his Pacific Action sail (below left) and shoot down across the Reach, with me clinging to Jeff’s hefty sea kayak. There’s a bit more Pacific Action sailing action attached to an Incept K40 in this video.
To me, sailing a kayak or packraft is a smart idea in the right conditions and with kayaks, some people think so too. The now moribund US-dominated packraft forum didn’t get so excited when a bloke demo’d his WindPaddle (see below); perhaps in the US most packrafters do rivers, not lakes or certainly not sea. In Scotland where the lochs can be long wind-channels and the boggy ground alongside horrible to walk over with a full pack, sailing a packraft down a 20-km valley full of water in half the time it would take to paddle makes sense.

V-sails and Umbrella sailing
I never got round to fitting a Pacific Action sail [left] onto the Sunny IK. In the UK they cost around £250 but it’s more or less two sticks and a sheet and some string. Here is a great thread on SotP about making your own V-sail, although now I notice the original model of the PA sails going for as little as £160 in the UK to make way for the new, mostly clear models.
I read about a guy who mentioned he umbrella-sailed his packraft back across an Arizona lake on an afternoon breeze. So with an old brolly I’ve barely used in 20 years, I gave it a go.

First time was in the Sunny kayak on a very windy day – too windy in fact. I found an out-of-the-way loch on the north side of Stac Polly mountain, hacked into the 20 mph headwind, turned round and opened up the umbrella expecting to catch the wind and rip back to the shore like an ekranoplan. No such luck. In a way the good thing with a brolly is that it inverts long before it drags you out of the boat and across the lake like a character from a cartoon. But because of that in-built safety overload, I couldn’t get going. Oddly, all that happened was instead of the bow coming round downwind, the boat kept getting side-on until the brolly inverting on a gust. Why side on? Was it the fact that the sail’s pivot point was effectively my shoulder in the middle of the boat, and not a point fixed on the front end? Could be.


A few days later I tried with my much lighter Llama packraft, but this rare day there was not enough wind to prove anything. As you can see left, I tried to use the paddle as a rudder, but on that day it would have been better used in its traditional role.

Flip-out disc sails
Since thenflip-out’ disc sails came to my attention: lighter, simpler and more compact than a PA. They work like those clever flip-out tents (see below): release a sling and it springs into shape on an unfurling hoop or batten. I made myself one from a spare tent.

Here is a great IK page by a French gonflard, Andypink picturing all sorts of kayak sails and having assessed all out there, he designed a 1.2m2 ‘spoon sail‘ which is now being sold by Bic (right) for about £50 – just under half the price of a smaller US-made WindPaddle (good canoer’s review here). As you’d expect, the places selling the Bic in the UK merely parrot the blurb from Bic  with no detailed analysis or photos of it in use. To do that you have to dig into Andy P’s blog; there are photos of an actual Bic-in-action here and here and especially here (also left, his picture cropped for clarity). You can see there are no less than three attachment points on each side of the sail.
Having used my similar but ultra-basic home-made version, I’d say the properly designed Bic differs in the following ways:

  • It has a window – always nice to see what’s ahead.
  • I assumed the inverted teardrop shape would make it unstable, but I suspect the close base-mount points make it easier to pull the sail hard down to one side for angling off the wind at up to 45°. And like a PA, it’s bigger up top where there’s significantly more wind.
  • The ‘control string’ attaches to the side of the sail at three points and then is attached to the hull (not one point and held in the hand like my MYO disc). I presume they are all chosen in position and length to maintain a certain optimal form.
  • It appears the dishing as featured on a WindPaddle and its knock-offs is not necessary.

Here’s a good intro to kayak sailing on Douglas Wilcox’s inspiring Scottish sea kayaking blog. DW paddles hardshells mostly, has actual sailboat experience and these days uses a fixed Flat Earth sail (a jib?) which I don’t think would work on an IK.
Douglas told me that on the faster boats they all use (proper sea kayaks with bows sharp enough to cut week-old brie) the WindPaddle proved to have a fairly narrow range of operational effectiveness (same with the Bic I imagine). In a strong wind the flexible hoop distorts and loses effectiveness; and in a light wind they find it’s barely worth the bother. But don’t forget this is in a slick kayak that can easily be paddled at 5mph while slicing through the swell. A packraft manages about half that and fast IK like a Seawave or Incept maybe 70-80% of that speed. So at the lower wind speeds I can paddle, a sail may be worthwhile – and in sail-distorting high winds; well, it didn’t happen with mine in 20mph winds (F4-5). I didn’t go that fast, but I can’t see me voluntarily being out at sea at wind speeds of 30mph, which is F6. It’s F7 out the window right now, pelting down and the sea looks utterly grim.


A ‘0.9m2’ WindPaddle is the same size as my disc sail, left (ie: 1m diametre which = a radius of 0.5m x 0.5m x π actually = 0.785 m2, but perhaps the dishing makes a bigger area?). As this guy suggests, this may not represent great value for money for a nylon sheet in a hoop plus some string. My own disc sail seems to work OK, but I may end up trying a Pacific Action – see below. My only reservations might be that it’s yet more stuff and a Bic or PA may be a little more complicated to rig and operate than a plain old disc sail.

More kayak and packraft sailing thoughts
I forget of course that my disc sail was primarily made as a portable sail for my packraft; I never really expected it to work on what was my Incept IK, but having done so anyway, I think at 0.78m2 it’s too small and too low. I block much of the backwind and I’ve been told the higher a sail the better it works; it’s just that too much height can affect stability in a gust. We don’t want that.

We were out yesterday on Loch Broom with Steve and Micheal in the Feathercrafts and me in the K40. By the time we finally put in at the back of the loch near the river, it had gotten windy and the fetch up the valley was pushing up a short chop which mid-loch, made forward progress slow. But now I have a nifty way of carrying my disc sail securely and out of the way on the Incept (right), I went right ahead and deployed it for the return. As before, I found that a stiff headwind paddled into at 2-3mph (see graph, left), didn’t correspond into a scintillating downwind glide under sail. Top speed was just over 4mph at which point things begin to get interesting and you want more. But most of the time Steve was able to keep up and even take pictures between paddling his Kahuna, so all I was gaining was some rest rather than extra speed.

Nothing wrong with resting on the move, but compact and handy though it is, I think my home-made disc sail is too small to get the K40 moving with my weight in it, let alone adding a camping payload. Researching more about V-sails, including the SotP thread mentioned above, I see that here and there PA sails are getting discounted to nearly the same price as a WindPaddle.

sai-sailor

Having thought it over and actually seen one in use, a PA is more like the real thing compared to any disc sail, whose USP is that they’re compact and deploy in a flash. What a WindPaddle, Bic or my home-made disc sail can’t do so easily on the water in anything longer than a packraft is fold up easily. On an Alpacka you just reach forward and twist the disc sail down out of the way and clamp it, but alone on a choppy sea in a long kayak, it’s far out of reach on the bow of my Incept, unless I just pull it back and lash it down over my knees. A headwind would hold it in place like that, but one may have other things on one’s mind in heavy conditions and a side- or backwind gust could catch it where it might dig into the water and act as an unwanted sea anchor, upsetting the boat. We don’t want that either.


Update – a cheap Windpaddle knock-off
So, having experimented with the concept of kayak sailing for little outlay, I can now see the value in actually buying something like a PA that’s made for the job, partly because we’re intending to paddle the Ningaloo this September where a sail will be useful, and sail-savvy Jeff (left) will be there to give me some tuition in the art. Short version: it didn’t go so well for me.
Where’s a windy day when you want one? Not today, but the next time I must take the Alpacka Yak out with the disc sail and see if the new shape and a bit more experience makes any difference. As you can see here, it wasn’t so conclusive with the old shape Llama on a reservoir in Surrey, but the pointier Yak, a bit of paddle rudder finesse and a stiff Hebridean breeze may make a difference.

Pic below: not given up on WindPaddle sailing yet.

coi - 8

Fitting a Pacific Action sail on Incept K40

See also this post as well as this post about using the PA in strong winds in Western Australia. There’s a video there too.

I’m pretty sure my 0.78m2 home-made disc sail is too small to push the 4-metre Incept along until wind conditions get beyond the pale. Recognising that, I tracked down a 1.5m Pacific Action for £175 instead of the usual £250 which is a bit much. As I mention here, you can easily make a V-sail yourself from bits of plastic piping and old trousers, but life is short and as I’ve experienced a PA in action in Shark Bay, I’ve treated myself. The nearest B&Q hardware store is half a day away.

They call it a ‘1.5m’ sail, but unless I am very much mistaken it’s more like 1.15m2 if you calculate the area of the Isosceles as 146cm across the top and 174 up the sides (graphic on right; or base x height of about 170 divided by 2). PA round those dimensions up on their website to 150cm and 180cm,  but that still doesn’t add up to 1.5m2 or 16 square feet. Maybe I should chill out a bit; a Ducati 900SS is actually 864cc and so on. As you can see left, it’s about twice as big as my 0.78m2 disc sail and it certainly looks like a metre-and-a-half square, so perhaps my sums are wrong. And it’s bigger in the right area too: up high where it counts. Plus you can see where you’re going – always handy in busy traffic lanes.

The sail comes in a compact bag of less than a metre. Can’t weigh things here but they claim 1.9kg; could even be less. Inside you get the two, 3-part masts made of thick glass fibre, the sail, fittings and rigging or lines, plus adequate instructions* for what turns out to be a fairly straightforward task. These instructions and fittings are obviously aimed at hardshells, be they SinKs or SoTs. With an IK you have to improvise a little. It helped knowing that there’s a picture of a PA sail on the Incept website (right), as well as this Kiwi guy’s video (bottom of page). The supplied cleats (sliding cord locks) are tiny and I recall Jeff replacing them on his Perception tandem for Shark Bay, but see below. Because of the confusing instructions combined with my congenital density, I misunderstood their simply application. On my first go at sailing the PA I was holding and maneuvering the control string by hand, as I did with the disc sail.

Up front the snaplinks (right) I’ve used to mount the disc sail also happen to be ideal positions for the PA’s webbing loop. And the bow handle ring toggle is the just about the minimum 12 inches ahead of the mast feet to take the shock cord clip (left) with which the sail springs forward when you release it. If that’s not quite enough far forward (as I think may be the case), I can stick a D-ring patch a few inches further forward right on the nose of the boat (as left). This position/angle may be more important than just getting a good spring forward, but also affect the sail support. We’ll see.


In Australia a few months later we did see. Further forward was indeed better, but I suspect still not optimal. When you think about it, the front attachment for the elastic would be better if it was set higher that the level of the mast feet. That’s because when you’re reaching across the wind with the downwind mast almost horizontal with the hull (as pictured left), the angle of leverage to keep the upper mast up gets very low; at 5-10° the tensioned elastic is almost at the same angle and so the sail collapses as shown in this video at 1.16. This happened to me all the time in Australia as the sail was pulled low to cope with the strong sidewinds. If I go ahead with my nasal bowsprit idea as mentioned here, I’m now thinking it might also be an idea to raise it a bit; have an upcurved bowsprit so the sail is more readily held up when reaching (near-horizontal).

While in Australia I also pushed the snaplinks to mount the sail straps directly through the black lugs and not around them as pictured right. This was because the strong wind was pushing the sail mount (a plastic plate) forward, making it go slack, reducing the elastic tension and causing more problems with handling. But by the time I made all these adaptions we were locked into two days of headwinds so I never really had a chance to see if it made any great difference.


Back to the original mounting story set in Scotland in summer 2011. It all went together easily enough, until it became clear some fittings were missing from the pack which for some reason looked like it had done the rounds with a few previous customers. Most fittings were not needed for my IK, except the four ¾-inch self tappers with which you permanently fix the mast feet position in relation to your kayak’s deck angle and with the sail splayed. According to the instructions* and this picture I found on the web this is an ‘8g ¾-inch’ screw, but that seems way too long to have two from opposing sides – one alone would act more as a bolt than a self-tapper getting a bite, but that is what they recommend; the subtext is these screws are important to make a solid fixture. What’s not made clear (or is perhaps obvious) is that you ought to pre-drill guide holes deep into the plastic mast feet lugs for the screw can get right in there. Some hardshells will have a bevelled or convex foredeck which is why you must set the mast foot angle (MFA) specific to your boat for optimum operation. On my set up, the MFA is horizontal (flat) as I’m using a plastic chopping board idea as PA suggest to give the feet the all-important support and avoid wear on the PVC deck. The feet move around quite a lot under tension as you pull the sail this way and that but, as I found first time out, the angle of those feet against the mast (as well as the webbing tension) must be solid if the sail is to spring up and open or splay out.

The sail rolls down out of the way and doesn’t interfere with paddling, though it does mean yet more cordage hanging around; you could get in a right old muddle if you don’t keep on top of it. PA do advise paddling with a knife or a less pointy rope cutter. I have a quick-grab Benchmark one (left) attached to my PA.


It was gusting up to 40mph before the local weather station packed up, and at times the sea was covered in foam streaks and swell, so I went to a back loch for a spin. Typically by the time I’d crawled into a dry suit in case I fell out and got dragged along by the sail, the wind had just about died, but it gave me a chance to test it out in tame conditions. That evening my paddling speeds back into the wind were greater than anything I managed under sail, but I was getting the hang of it and even got the knack of running almost across the wind. The vid from that session isn’t worth uploading unless you’re having trouble sleeping; I hope to have another session when the wind returns and on a loch that’s longer to the wind.
Lessons learned: need those self tappers to lock the feet, luckily the local store had some that may do the job. And I’ve since located that chopping board a bit better to the boat with some slots and zip ties until a better solution is required.

Rigging the sail-adjusting cleat
Working out how to rig the control cord to alter the sail angle was actually rather simple once I put my mind to it. As mentioned, you get some small plastic cleats in the pack whose use is unclear. But digging around online for an alternative cleat (as other PA users tend to fit), I discovered what the PA comes with are very much like, if not exactly Clamcleat Line-Loks. Now I know what they are, their fitting and application is more clear. It’s not illustrated or explained in the PA instruction leaflet* I received; in fact I’d go as far as to say that the tiny yellow picture of the rigged Line-Lok in the PA leaflet is the wrong way round compared to what’s illustrated in the Clamcleat gif on the left. But even though (as I found) it does work crudely when rigged the wrong way round, I think I finally get it now. A Line-Lok a nifty solution to tensioning a tent guy in the Arctic as the link shows, but as Clamcleat’s gif on the above right also illustrates, you need two hands to release it – not something that may be easily available in rough conditions while trying to grab your paddle and not spill your tea. But so far I’ve found in the light conditions I’ve been out in, one-handed works fine and if it’s a real panic you just pull the sail down in a jiffy.
In fact, testing the correctly rigged locking cleat off a chair leg, it’s possible to achieve the release movement by spreading your fingers as long as it’s not too tightly jammed in the cleats, while adding tension (pulling the sail back/down) is certainly easy.

Having worked out how to string them up, the next question is where to attach them to the boat. By trial and error I found that cutting the supplied 4-5m line in half, rigging as above and then clipping the stainless steel clip to the K40 at the plastic lugs just behind the seat seems just right (left; it shares the left side lug with the rudder lifting line). Even though the Incept image with the red boat above seems to use the more forward points, fixed like this it puts the full sliding range of the locking cleat within arm’s reach while sat in the cockpit; or at least that’s how it looks on the lawn. I used the spring clips supplied to fix the control cord to the mast shackles, but at one point while sailing one unhooked itself from the shackle, so better to knot the cords securely to the shackle as PA recommend. To see how it sailed first time out, see this.

NB: A more recent set of fitting instructions were sent to me as a pdf from Pacific Action and are much clearer.
As far as I could see it wasn’t to be found on their website.

Packraft MYO sailing

See also this

First sunny spring day around here so we went out to try out the flip-out disc sail I made over the winter on my Llama and Steve’s Big Kahuna. Wind was forecast at about 8 mph but was gusty – a bloke in a dinghy sailboat said it was up to 15 mph.
Folded and clipped on the packraft, the sail sits out of the way and can be opened and – more importantly – closed easily with a twist, as long as you have a clip of some sort to keep it closed (and that clip is attached to the sail so it does not spring off and sink to the bottom of the lake…).

Initial impressions were disappointing, I did not rip off across the reservoir like a hooked marlin out of a Roadrunner cartoon. But watching the vid back it’s clear the boat did noticably drift downwind across the reservoir with the sail aloft, often at speeds similar to paddling (about 3 mph). Problem with the sail on the Alpacka was the boat soon turned off the wind one way or the other, swinging left and right. The pointier Kahunayak was better, especially once Steve trailed his paddle like a skeg. Didn’t get to try that on the Llama as I was fiddling about with the string trying angle the sail so as to steer the boat into the wind. This worked quite well in correcting the direction as you can see in the vid, but staying in that position was a problem.
Could this be due to ‘wind-spill’ off the flat disc sail which lacks dishing like a WindPaddle? Maybe. It will be interesting to try it on my ruddered Incept IK when it turns up, as well as the new-shape Alpacka which I am picking up next week.
More testing to come this summer up in windier Scotland with my all-new packboating flotilla. Or just enjoy this 2014 video from Finland by JP. More here at leftbound.

Homemade packraft or kayak sail

For my original post on the idea of IK sailing, with various videos, click this
For my first go packrafting with the sail, click this, and in a kayak, see this
A cheap ‘Windpaddle’ sail

A few years ago I got a batch of discounted Decathon Quechua ‘2 seconds 1’ pop-up tents (right; £20) for a desert tour I was running, and have a couple leftover. Now everyone’s offering cheap pop-ups. People love the idea and though I don’t suppose this is a tent you’d want on the north face of Annapurna in a gale, when you arrive at a camp tired after a day of desert biking, you just want to click your fingers and, Abracadabra, you have a cozy shelter to call your own.

Whoever came up with the idea of flexible hoops sewn into a 3-D form to spring apart and make a tent or shelter was ingenious. I still marvel at it today. It seems a photographer John Ritson got to idea of adding fabric to a flat loop in 1985 and invented the collapsible Lastolite light reflector (right) after he saw a carpenter fold the blade of a bandsaw (See the bottom of this page). I imagine a Lastolite (a 38-incher costs £50) was the motivation behind the WindPaddle idea, but from a plain disc to a tent is quite a leap.

So I took a knife to one of my used Quechua tents.  Bad though it felt shredding a perfectly functional shelter, in the spirit of the Inca shaman, it will be reincarnated as a sail – or more ill-conceived clutter to shove under the bed.
Dismembering the Quechua gives two giant hoops of 4mm nylon-coated alloy and another of 6mm. Having been told that WindPaddles can deform easily under strong winds, I chose the thicker wire to use for the hoop (Gallery pic 2, below) in the hope of reducing this possibility. (Warning: when opened up these springy wires can fly about all over the place).

Cutting the thick loop in half and rejoining it with the metal collar/tube (don’t lose this bit) gives a hoop of around 40 inches or 1 metre diametre making a sail area of 0.785 m2 (8.45 ft2) – similar to a WindPaddle, but with negligible dishing. I built up the sawn-off end with some cloth tape to stuff into the collar-tube, and then taped it all up (so it’s easily undoable).
There’s enough fabric in the main body of the tent’s flysheet (Gallery pic 1) to make two 40″ disc sails if you cut from the middle, so 1 tent fly = 2 sails. I only worked this out after I cut. You want to use each curved end of the flysheet with as much orange hem-sleeve as possible (Gallery pic 4) – it saves on sewing later. You don’t want, as I thought,  the flat middle section which of course won’t become a smooth disc once formed into a loop with the wire. Gallery pics 5 to 9 show how to gather up the slack, trim it, tack it down and get the Mrs to sew it up as if she hasn’t got enough work to be getting on with at this time of year.
Gallery picture 10 is the sewn-up sail with a handy gap at the bottom for I don’t know what and which also happens to coincide with the position of two little hooped tabs at 5- and 7 o’clock which you can use mount it to an Alpacka’s rearmost bow loops using mini snaplinks (Gallery picture 11). By chance there are 2 more sewn-on plastic rings at 10- and 2 o’clock to mount a control string. The length of string I used happened to be just right to wrap around the folded over tent, though it’s all under tension and pretty unstable; you might want something like a bulldog clip to stop the sail deploying unexpectedly. I also think my control string may be on the short side, but it’s what was lying around.
My disc tent doesn’t have anywhere near the dishing (depth) of a WindPaddle or an umbrella-like spinnaker sail I am told. I still haven’t worked out if this is significant (it is). One would imagine a deeper WP-like sail – a ‘bowl’ rather than a ‘saucer’ – would be more stable downwind but less good at tacking across it (probably correct) but what do I know? Last time I sailed a boat was over 35 years ago.
I suspect a flip-out disc sail like this is probably a compromise when it comes to sailing effectively, but then so are pack boats. If round sails were such a good idea the Vikings would have them. It may even prove to be not fully useful and so just more junk to carry about which is why, after trying the umbrella, I chose to make one for next to nothing rather than spend £140 ($215) on a WindPaddle in the UK. It was easy to make, is light (250g or 9oz), and it can swapped between my Alpacka packraft and Sunny IK in the time it takes to unclip 2 snaplinks and attach them elsewhere.
Other uses include something to sit on, a doormat for the tent, a windbreak, sunshade or umbrella. There is a slight problem: you can’t see where you’re going, especially on the shorter packraft with a metre-wide sail a metre on front of you, but on most water that ought not matter too much and if it does, I can cut in a window (like a WindPaddle) if that is the sail’s only flaw.
As to how it sails, Monday after Christmas had a good southerly wind and the warmest day for weeks (ie: above freezing), but the reservoir I chose was a rink and looks like it’ll be that way for a while. It’s been the coldest December in the UK since records began so a test run make take a few weeks to complete. To see how it sailed first time out, click this.
